Features:
- Programmable input voltage range 0 to 600V AC(RMS) or DC
- Adjustable response delay from 0.1 to 10 seconds on SP201
- Voltage threshold adjustable on calibrated scale, 0-100%
- Adjustable hysteresis 5-30%
- Programmable for over-voltage or under-voltage detection
- Latching on over-voltage or under-voltage
- 10A SPDT relay output
Specification:
Power Supply:
AC: Supply voltage: 12, 24, 115, 230, 400, 415, 525V ±15%
Isolation (current input to power supply): 2kV
Power consumption: 3VA (approx), 6VA for 415, 525V(approx)
DC: Supply Voltage: 10-30V, 48, 60, 110V ±15%
Isolation: No galvanic isolation
Power consumption: 100mA (10-30V), 30mA for 48V and higher
Voltage Input:
Repetitive accuracy: 1%
Hysteresis: 5% to 30% (adjustable)
Response:
Response delay: SP200 – 1 second
SP201 – adjustable from 0.1 to 10 seconds (other ranges on special order)
Latching disabled during power-up: approx. 10 seconds
